Robustus one head cutting machine
Robustus one head cutting machine
, ,

Robustus One Head Cutting Machine (TMX 650/1)

Robustus one head cutting machine. Automatic machine for multiple linear cutting with diamond discs. Suitable for cutting ceramic tiles of any kind, marble, granite, glass, and bricks.

Specification:
Maximum working thickness: 20mm (porcelain), 30mm (marble)
Minimum standard format obtained: 50mm
Maximum cutting width: 600mm
No of cutting discs: 6
Diameter of cutting discs: 300mm
Belt width: 650mm
Cutting motor power: 11.2kW 2800 rpm
Maximum dimensions: 2300 x 1300 x 1900mm
Weight: 850kg

SKU: TMX 650/1 Categories: , , Tags: ,
Add to quote

Robustus one head cutting machine.

ADVANTAGES OF TMX 650/1 ROBUSTUS

  • Side opening for large sizes.
  • Hyper-static lateral support of the motor shaft for stability and anti-vibration.
  • Autonomous water recycling and/or possibility of connection to general recycling system.
  • 650mm cutting belt.
Weight850 kg
Production Size

Large

Range

Compactline, Industrialine, Robustus
